1 / 6Ozone Generator — Light Industrial 5g/hr
Light industrial ozone generator for small water treatment plants and commercial disinfection
The OZ India 5g/hr Light Industrial Ozone Generator produces 5 grams of ozone per hour using corona discharge. CE certified CE-2621A, ISO 9001:2015. For small STPs, swimming pools, pharmaceutical water, commercial kitchens. Exports to Kenya, UAE, Nigeria, Bangladesh.
CE & ISO 9001:2015 certified manufacturer · Est. 2014 · 150,000+ installations · Greater Noida, India
Light industrial ozone generator — also called an ozonator or ozonation system — for continuous dosing at small-to-medium scale. Applications: small STPs, swimming pools, pharmaceutical purified water, commercial kitchen disinfection, food storage cold rooms. Features digital display, adjustable output 10-100%. CE certified and ISO 9001:2015 compliant.
| Ozone Output | 5 g/hr |
|---|---|
| Technology | Corona Discharge |
| Feed Gas | Ambient Air or Oxygen optional |
| Power Supply | 220V AC 50Hz Single Phase |
| Power Consumption | 100-150W |
| Display | Digital LCD |
| Controls | Microprocessor |
| Certification | CE-2621A, ISO 9001:2015 |
| Warranty | 12 months on-site |
- Optional oxygen concentrator integration
- Digital display showing system status
- Compact vertical cabinet
- CE and ISO 9001:2015 certified export ready
VIDEOS
See Ozone Generator 5g/hr in Action
INDUSTRY APPLICATIONS
Where Ozone Generator 5g/hr is Used
COMPLETE OZONE SYSTEM
System Components & Accessories
Every ozone generator installation requires these supporting components for safe, compliant, and efficient operation.
Related Products
Frequently Asked Questions
The 5g/hr light industrial ozone generator is used for small STP/ETP disinfection up to 1,000 L/hr, swimming pool ozonation for pools up to 100,000 litres, cold storage rooms up to 500 m³, small aquaculture tanks, and food processing wash water treatment in restaurants and small food plants.
The 5g/hr unit operates on dry compressed air (oil-free compressor with built-in desiccant dryer included) and produces ozone at 3–5 wt%. An optional oxygen feed from a PSA oxygen generator can increase output to 7–8 wt% for demanding applications.
The 5g/hr unit consumes approximately 100–150 W at rated output, equivalent to running two 60W light bulbs. It operates on standard single-phase 230V/50Hz power. A dedicated 15A circuit is recommended.
A venturi injector is available as an accessory and is recommended for all water treatment applications. The standard unit ships with the ozone generator only; the complete system with venturi injector, PVDF tubing, and ambient air monitor can be ordered as a system package.
