1 / 6UV Industrial Series — 2000 to 20000 LPH
Industrial UV water disinfection 2000–20000 LPH — multi-lamp SS304 reactor, SCADA ready
UV Industrial Series 2000–20000 LPH by Ozone India Technology, Greater Noida. Multi-lamp SS304 reactor, genuine quartz sleeves, UV intensity monitor with 4–20 mA SCADA output. For pharma, food & beverage, STP, ETP. CE certified.
CE & ISO 9001:2015 certified manufacturer · Est. 2014 · 150,000+ installations · Greater Noida, India
The OZ Industrial UV Series handles 2000–20000 LPH for demanding process water, food & beverage, and effluent polishing applications. Multi-lamp horizontal or vertical SS304 reactor with flanged connections. UV intensity monitor with 4–20 mA analogue output and RS485 Modbus for SCADA/BMS integration. Automatic solenoid valve shuts flow on UV intensity alarm.
| Flow Rate | 2000 LPH to 20,000 LPH |
|---|---|
| UV Dose | ≥40 mJ/cm² at end-of-lamp-life |
| Reactor | SS304 horizontal/vertical, flanged |
| Quartz Sleeves | Genuine fused silica, individual replacement |
| UV Monitor | Online sensor, digital display |
| Safety | Digital Indicator on Lamp Failure |
| Power | 230 VAC 50 Hz |
| Lamp Life | 9000 hours |
| Certification | CE, ISO 9001:2015, NSF/ANSI 55 |
- 2000–20000 LPH — single unit, no parallel skids needed
- Multi-lamp reactor — redundancy; system works even on partial lamp failure
- UV intensity monitor — validates actual dose delivered, not just lamp status
- Auto solenoid shutoff — stops water flow on UV intensity alarm
- Flanged SS304 reactor — food and pharma grade
- CE certified, ISO 9001:2015
INDUSTRY APPLICATIONS
Where UV Industrial Series is Used
Related Products
Frequently Asked Questions
Low-pressure mercury UV lamps are rated for 9,000–12,000 operating hours (approximately 1–1.5 years at continuous operation). UV output degrades by 10–15% per year — replace when the UV intensity monitor reads below 70% of the initial calibrated value, or at least every 18 months regardless of intensity reading.
BIS IS 10500:2012 requires E. coli to be not detectable in 100 mL of treated water. A UV dose of ≥25 mJ/cm² reliably achieves this. Ozone India Technology UV systems are designed to deliver ≥40 mJ/cm² at end-of-lamp-life, providing a safety margin for variable water quality conditions.
No. UV disinfection is a purely physical pathogen inactivation process — it does not remove any dissolved or suspended contaminants. Water must be pre-treated to <1 NTU turbidity before UV treatment. For complete water purification including TDS, hardness, and chemical removal, combine UV with RO and/or ozone treatment.
UV systems are sized for specific UVT values. Ozone India Technology systems are standard-rated at ≥85% UVT (typical drinking water after filtration). For low-UVT water (coloured groundwater, post-secondary treated sewage at 60–70% UVT), the system is sized with additional lamp power to compensate. Provide your water's UVT% when requesting a quotation.
Yes. All UV water treatment systems carry CE marking under EU Machinery Directive 2006/42/EC and are manufactured under ISO 9001:2015 QMS. CE documentation supports export to EU, GCC, and other markets requiring CE certification for imported water treatment equipment.
