1 / 3Salt Spray Test Chamber
Salt spray corrosion test chamber SS316 per ISO 9227 ASTM B117 for metal coatings plating and surface treatment testing
OZ India Salt Spray Test Chamber for accelerated corrosion testing of metal coatings, plating, and paints per ISO 9227 and ASTM B117. SS316 interior, precise pH and temperature control, CE certified. Ozone India Technology, Greater Noida.
CE & ISO 9001:2015 certified manufacturer · Est. 2014 · 150,000+ installations · Greater Noida, India
Salt spray (salt fog) test chambers for accelerated corrosion testing of metal parts, coatings, electroplating, paint, and anodising. Produces continuous 5% NaCl salt fog at 35±1°C with precise pH control (6.5–7.2) per ISO 9227 neutral salt spray (NSS), acetic acid salt spray (AASS), and copper-accelerated acetic acid salt spray (CASS) standards. SS316 interior and corrosion-resistant polypropylene cabinet. Timer-controlled test cycle. Applications: automotive body panels and fasteners, marine hardware, electroplated components (zinc, chrome, nickel), painted and powder-coated parts, decorative hardware, and BIS quality control testing. CE certified, ISO 9001:2015.
| Salt Solution | 5% NaCl neutral salt spray |
|---|---|
| Test Standards | ISO 9227 NSS AASS CASS / ASTM B117 |
| Temperature | 35 ± 1°C chamber, 47 ± 1°C saturator |
| pH Control | 6.5–7.2 (NSS) / 3.1–3.3 (AASS) |
| Volume | 60 to 1000 litres |
| Interior | SS316 anti-corrosion liner |
| Cabinet | Polypropylene corrosion-resistant |
| Certification | CE, ISO 9001:2015 |
- ISO 9227 and ASTM B117 compliant — NSS, AASS, and CASS test modes
- SS316 interior — immune to salt fog corrosion attack
- Precise pH control — meets strict standard pH tolerances
- Timer controller — programs test duration from hours to thousands of hours
- Multiple volumes 60-1000 litres — bench-top to large panel testing
- CE certified for automotive, marine, and export quality testing
INDUSTRY APPLICATIONS
Where OZ Salt Spray Chamber is Used
Related Products
Frequently Asked Questions
Test chambers are supplied with calibration certificates for the primary measurement parameters (ozone concentration, temperature, humidity) traceable to national standards. The calibration documentation is formatted to support NABL-aligned laboratory accreditation requirements and ISO 17025 quality system audits.
All test chambers carry a 12-month warranty from installation date covering parts and labour. Annual Maintenance Contracts (AMC) covering 2 preventive maintenance visits, calibration, and priority support are available from ₹18,000–45,000/year depending on chamber type and size.
Yes. All Ozone India Technology test chambers include a microprocessor PLC controller with programmable ramp-and-soak temperature/humidity profiles (up to 99 segments). This is required for cyclic ageing tests per IEC 60068-2-14 and similar standards. Data logging to USB/SD card is standard.
Yes. The range covers temperature-only chambers (temperature: -70°C to +180°C), humidity chambers (temperature: 10–85°C; humidity: 20–98% RH), combined environmental chambers (full temperature-humidity cycling), and specialized chambers for salt spray, xenon weathering, ozone ageing, and UV weathering.
