1 / 3Temperature Chamber
Precision temperature test chamber -40 to 200 degrees C for electronic automotive and component thermal testing
OZ India Temperature Chamber for precision thermal testing -40 to 200 degrees C with ramp rate up to 5 degrees C per minute. CE certified IEC 60068-2-1 and -2-2 compliant. For electronics, automotive, defence component temperature testing. Ozone India Technology, Greater Noida.
CE & ISO 9001:2015 certified manufacturer · Est. 2014 · 150,000+ installations · Greater Noida, India
Precision temperature-only test chambers for thermal shock, temperature cycling, high-temperature soak, and cold storage simulation from -40 to 200 degrees C. Used where humidity is not required — electronics thermal qualification, automotive component soak testing, plastic thermal deformation, paint and coating cure verification, sterilisation validation. Fast ramp rate up to 5 degrees C per minute for thermal shock cycling. PLC controller with programmable multi-step profiles, data logging, over-temperature safety cutout. Custom sizes from 64 litres bench-top to large floor-standing models. CE certified, IEC 60068 compliant.
| Temperature Range | -40 to +200 degrees C |
|---|---|
| Temperature Accuracy | plus minus 0.5 degrees C |
| Ramp Rate | Up to 5 degrees C per minute |
| Volume | 64 to 2000 litres custom |
| Safety | Over-temperature cutout independent |
| Controls | PLC with programmable profiles |
| Data Output | USB RS485 |
| Certification | CE, ISO 9001:2015, IEC 60068 |
- Wide range -40 to 200 degrees C — single chamber for cold and hot tests
- Fast ramp rate 5 degrees C per minute — efficient thermal cycling
- Independent over-temperature cutout — protects samples and chamber
- Programmable multi-step profiles — complex thermal sequences automated
- CE certified IEC 60068 compliant — for automotive and defence qualification
- Custom sizes — from R&D bench-top to production floor-standing
INDUSTRY APPLICATIONS
Where OZ Temp Chamber is Used
Related Products
Frequently Asked Questions
Test chambers are supplied with calibration certificates for the primary measurement parameters (ozone concentration, temperature, humidity) traceable to national standards. The calibration documentation is formatted to support NABL-aligned laboratory accreditation requirements and ISO 17025 quality system audits.
All test chambers carry a 12-month warranty from installation date covering parts and labour. Annual Maintenance Contracts (AMC) covering 2 preventive maintenance visits, calibration, and priority support are available from ₹18,000–45,000/year depending on chamber type and size.
Yes. All Ozone India Technology test chambers include a microprocessor PLC controller with programmable ramp-and-soak temperature/humidity profiles (up to 99 segments). This is required for cyclic ageing tests per IEC 60068-2-14 and similar standards. Data logging to USB/SD card is standard.
Yes. The range covers temperature-only chambers (temperature: -70°C to +180°C), humidity chambers (temperature: 10–85°C; humidity: 20–98% RH), combined environmental chambers (full temperature-humidity cycling), and specialized chambers for salt spray, xenon weathering, ozone ageing, and UV weathering.
