1 / 3Environmental Chamber
Combined temperature and humidity environmental test chamber -40 to 150 degrees C for product reliability testing
OZ India Environmental Chamber for combined temperature and humidity product reliability testing. Range -40 to 150 degrees C, 10-98 percent RH. PLC controlled, CE certified. For electronics, automotive, defence, consumer goods qualification. Ozone India Technology, Greater Noida.
CE & ISO 9001:2015 certified manufacturer · Est. 2014 · 150,000+ installations · Greater Noida, India
Combined temperature and humidity environmental test chambers for product reliability, durability, and qualification testing. Temperature range -40 to 150 degrees C, humidity range 10-98 percent RH, programmable profiles for thermal cycling, humidity soak, cold start, and accelerated ageing. PLC with touchscreen HMI, automated profile execution, data logging, and RS485 output. Applications: electronics component qualification, automotive parts HALT HASS testing, defence equipment MIL-STD testing, consumer electronics qualification, paint and coating testing. Custom sizes from 64 litres bench-top to 2000 litres floor-standing. CE certified.
| Temperature Range | -40 to +150 degrees C |
|---|---|
| Temperature Accuracy | plus minus 0.5 degrees C |
| Humidity Range | 10-98 percent RH |
| Humidity Accuracy | plus minus 2 percent RH |
| Chamber Volume | 64 to 2000 litres custom |
| Ramp Rate | Up to 5 degrees C per minute |
| Controls | PLC HMI with programmable profiles |
| Data Output | USB RS485 remote monitoring |
| Certification | CE, ISO 9001:2015 |
- Combined temp plus humidity — single chamber for all climatic tests
- Programmable profiles — thermal cycling soak cold start in one sequence
- Fast ramp rate up to 5 degrees C per minute — reduces test time
- Data logging with timestamps — test reports for qualification documentation
- Custom sizes 64-2000 litres — bench-top to large floor-standing
- CE certified for defence automotive and electronics qualification
INDUSTRY APPLICATIONS
Where OZ Env Chamber is Used
Related Products
Frequently Asked Questions
Test chambers are supplied with calibration certificates for the primary measurement parameters (ozone concentration, temperature, humidity) traceable to national standards. The calibration documentation is formatted to support NABL-aligned laboratory accreditation requirements and ISO 17025 quality system audits.
All test chambers carry a 12-month warranty from installation date covering parts and labour. Annual Maintenance Contracts (AMC) covering 2 preventive maintenance visits, calibration, and priority support are available from ₹18,000–45,000/year depending on chamber type and size.
Yes. All Ozone India Technology test chambers include a microprocessor PLC controller with programmable ramp-and-soak temperature/humidity profiles (up to 99 segments). This is required for cyclic ageing tests per IEC 60068-2-14 and similar standards. Data logging to USB/SD card is standard.
Yes. The range covers temperature-only chambers (temperature: -70°C to +180°C), humidity chambers (temperature: 10–85°C; humidity: 20–98% RH), combined environmental chambers (full temperature-humidity cycling), and specialized chambers for salt spray, xenon weathering, ozone ageing, and UV weathering.
