Dry heat aging oven test chamber 50 to 300 degrees C for rubber plastics electrical component thermal ageing
OZ India Oven Hot Test Chamber for dry heat ageing testing 50-300 degrees C with forced air circulation. CE certified. For rubber thermal ageing IS 3400, plastic heat deformation, electrical component temperature rating, food dry heat testing. Ozone India Technology, Greater Noida.
CE & ISO 9001:2015 certified manufacturer · Est. 2014 · 150,000+ installations · Greater Noida, India
Forced-air circulation hot air oven chambers for dry heat ageing and elevated temperature testing of rubber, plastics, electrical components, cables, food products, and pharmaceutical materials from 50 to 300 degrees C. Uniform temperature throughout chamber by forced air circulation. Applications: rubber thermal ageing IS 3400 and ASTM D573, plastics heat deflection and warping, cable and wire temperature rating per IS 5831, electrical component temperature class verification, food baking and heat processing, sterilisation of laboratory equipment. Digital PLC controller, over-temperature independent cutout, timed operation. CE certified.
| Temperature Range | 50-300 degrees C |
|---|---|
| Temperature Accuracy | plus minus 1 degree C |
| Circulation | Forced air motor fan |
| Volume | 50-500 litres |
| Timer | Digital 1-999 hours |
| Safety | Independent over-temperature cutout |
| Construction | Inner SS304 outer mild steel powder coated |
| Certification | CE, ISO 9001:2015 |
- 50-300 degrees C range — covers rubber ageing to sterilisation temperatures
- Forced air circulation — uniform temperature within plus minus 1 degree C
- Independent over-temperature safety — protects chamber and samples
- Digital timer to 999 hours — long ageing studies unattended
- IS 3400 rubber thermal ageing and IS 5831 cable testing compliant
- CE certified for quality lab production and R&D use
INDUSTRY APPLICATIONS
Where OZ Oven Chamber is Used
Related Products
Frequently Asked Questions
Test chambers are supplied with calibration certificates for the primary measurement parameters (ozone concentration, temperature, humidity) traceable to national standards. The calibration documentation is formatted to support NABL-aligned laboratory accreditation requirements and ISO 17025 quality system audits.
All test chambers carry a 12-month warranty from installation date covering parts and labour. Annual Maintenance Contracts (AMC) covering 2 preventive maintenance visits, calibration, and priority support are available from ₹18,000–45,000/year depending on chamber type and size.
Yes. All Ozone India Technology test chambers include a microprocessor PLC controller with programmable ramp-and-soak temperature/humidity profiles (up to 99 segments). This is required for cyclic ageing tests per IEC 60068-2-14 and similar standards. Data logging to USB/SD card is standard.
Yes. The range covers temperature-only chambers (temperature: -70°C to +180°C), humidity chambers (temperature: 10–85°C; humidity: 20–98% RH), combined environmental chambers (full temperature-humidity cycling), and specialized chambers for salt spray, xenon weathering, ozone ageing, and UV weathering.
