1 / 3Walk-in Test Chamber
Walk-in environmental test chamber for large assemblies automotive panels military equipment and batch product reliability testing
OZ India Walk-in Test Chamber for large assemblies, automotive panels, military equipment, and batch product reliability testing. Custom size, temperature -40 to 150°C, humidity 10–98% RH, CE certified. Ozone India Technology, Greater Noida.
CE & ISO 9001:2015 certified manufacturer · Est. 2014 · 150,000+ installations · Greater Noida, India
Walk-in environmental test chambers for testing large and heavy products that cannot be placed in standard bench-top or floor-standing chambers. Custom-built to accommodate automotive body panels, vehicle sub-assemblies, defence equipment, large electronics racks, industrial machinery, and batch testing of multiple units simultaneously. Temperature range -40 to +150°C, humidity range 10–98% RH, programmable profiles including thermal shock, humidity soak, HALT, and HASS cycles. Fork-lift accessible door with insulated threshold ramp. Reinforced floor rated for heavy loads. Applications: automotive OEM component qualification, defence equipment MIL-STD-810, aerospace sub-assembly testing, white goods and consumer appliance testing, batch production QC. CE certified, ISO 9001:2015.
| Chamber Volume | 4 m³ to 100+ m³ custom |
|---|---|
| Temperature Range | -40 to +150°C |
| Temperature Accuracy | ±0.5°C |
| Humidity Range | 10–98% RH |
| Humidity Accuracy | ±2% RH |
| Door | Insulated, fork-lift accessible |
| Floor Load | Reinforced heavy load rated |
| Certification | CE, ISO 9001:2015 |
- Custom walk-in size — from 4 m³ to 100+ m³ per requirement
- Fork-lift accessible door — large heavy assemblies enter easily
- Reinforced floor — handles vehicle sub-assemblies and equipment loads
- -40 to +150°C temperature plus 10-98% RH — full climatic envelope
- Programmable profiles — HALT HASS thermal cycling and humidity soak
- CE certified for automotive defence aerospace and industrial qualification
INDUSTRY APPLICATIONS
Where OZ Walk-in Chamber is Used
Related Products
Frequently Asked Questions
Test chambers are supplied with calibration certificates for the primary measurement parameters (ozone concentration, temperature, humidity) traceable to national standards. The calibration documentation is formatted to support NABL-aligned laboratory accreditation requirements and ISO 17025 quality system audits.
All test chambers carry a 12-month warranty from installation date covering parts and labour. Annual Maintenance Contracts (AMC) covering 2 preventive maintenance visits, calibration, and priority support are available from ₹18,000–45,000/year depending on chamber type and size.
Yes. All Ozone India Technology test chambers include a microprocessor PLC controller with programmable ramp-and-soak temperature/humidity profiles (up to 99 segments). This is required for cyclic ageing tests per IEC 60068-2-14 and similar standards. Data logging to USB/SD card is standard.
Yes. The range covers temperature-only chambers (temperature: -70°C to +180°C), humidity chambers (temperature: 10–85°C; humidity: 20–98% RH), combined environmental chambers (full temperature-humidity cycling), and specialized chambers for salt spray, xenon weathering, ozone ageing, and UV weathering.
