1 / 3Vacuum Test Chamber
Vacuum test chamber for space simulation outgassing leak testing and low-pressure electronics component qualification
OZ India Vacuum Test Chamber for space simulation, outgassing studies, leak detection, and low-pressure electronics component qualification. Down to 10â»â¶ mbar, custom sizes, CE certified. Ozone India Technology, Greater Noida.
CE & ISO 9001:2015 certified manufacturer · Est. 2014 · 150,000+ installations · Greater Noida, India
Vacuum test chambers for product testing under low-pressure and high-vacuum conditions simulating space environment, altitude, and vacuum process conditions. Applications include outgassing studies for spacecraft materials (NASA SP-R-0022A), leak detection and seal integrity testing, electronics component altitude testing per IEC 60068-2-13, composite material void analysis, food packaging vacuum seal QC, and low-pressure impregnation processes. Stainless steel SS304 or SS316 chamber with flanged access ports, observation window, and electrical feedthroughs. Pump packages from rough vacuum (10â»Â² mbar) to high vacuum (10â»â¶ mbar). CE certified, ISO 9001:2015.
| Vacuum Level | Down to 10â»â¶ mbar (customisable) |
|---|---|
| Chamber Material | SS304 or SS316 electropolished |
| Chamber Volume | 5 to 2000 litres |
| Access | Flanged ports, observation window |
| Electrical | Multiple feedthrough options |
| Pump | Rotary vane + diffusion or turbo |
| Leak Rate | < 10â»â¸ mbar.l/s (welded construction) |
| Certification | CE, ISO 9001:2015 |
- Down to 10â»â¶ mbar — space simulation and high-vacuum outgassing
- SS316 electropolished interior — low outgassing from chamber walls
- Observation window — monitor test samples without breaking vacuum
- Multiple electrical feedthroughs — power and signal to test samples
- Custom sizes 5-2000 litres — from component to sub-system testing
- CE certified for aerospace defence and electronics qualification
INDUSTRY APPLICATIONS
Where OZ Vacuum Chamber is Used
Related Products
Frequently Asked Questions
Test chambers are supplied with calibration certificates for the primary measurement parameters (ozone concentration, temperature, humidity) traceable to national standards. The calibration documentation is formatted to support NABL-aligned laboratory accreditation requirements and ISO 17025 quality system audits.
All test chambers carry a 12-month warranty from installation date covering parts and labour. Annual Maintenance Contracts (AMC) covering 2 preventive maintenance visits, calibration, and priority support are available from ₹18,000–45,000/year depending on chamber type and size.
Yes. All Ozone India Technology test chambers include a microprocessor PLC controller with programmable ramp-and-soak temperature/humidity profiles (up to 99 segments). This is required for cyclic ageing tests per IEC 60068-2-14 and similar standards. Data logging to USB/SD card is standard.
Yes. The range covers temperature-only chambers (temperature: -70°C to +180°C), humidity chambers (temperature: 10–85°C; humidity: 20–98% RH), combined environmental chambers (full temperature-humidity cycling), and specialized chambers for salt spray, xenon weathering, ozone ageing, and UV weathering.
