1 / 3UV Ozone Sterilization Chamber
Combined UV-C and ozone sterilization chamber for tools, instruments, and packaged goods
UV Ozone Sterilization Chamber by Ozone India Technology, Greater Noida, UP. Combined UV-C 254nm + ozone for deep sterilization of medical instruments, lab tools, food packaging. Available in MS and SS304. CE certified.
CE & ISO 9001:2015 certified manufacturer · Est. 2014 · 150,000+ installations · Greater Noida, India
Combined UV-C (254nm) and ozone sterilization chambers for thorough disinfection of medical instruments, laboratory tools, food packaging materials, currency, mobile phones, and small packaged goods. UV-C irradiates all exposed surfaces; ozone penetrates crevices and shadows UV cannot reach. Available in MS powder-coated and SS304 models. Timer-controlled cycle with automatic ozone exhaust fan.
| Chamber Sizes | Small (30L), Medium (80L), Large (150L), Custom |
|---|---|
| UV Wavelength | 254 nm UV-C germicidal lamps |
| Ozone Output | 200–500 mg/hr (built-in generator) |
| Sterilization | UV-C top/bottom + ozone gas — dual action |
| Material | MS powder-coated / SS304 (food & pharma grade) |
| Timer | 0–60 minutes programmable |
| Safety | Door interlock, exhaust fan, ozone sensor alarm |
| Power | 230 VAC, 50 Hz, <150W |
| Lamp Life | 9000 hours |
| Certification | CE, ISO 9001:2015 |
- Dual-action — UV-C surface irradiation + ozone gas penetration
- Reaches crevices and shadow areas UV alone cannot disinfect
- Available 30L to 150L and custom sizes
- SS304 option — food and pharma grade
- Automatic exhaust fan — safe ozone purge before door opens
- Door interlock — UV and ozone off when door opened
- Timer-controlled 5–60 min cycles
- CE certified, Make in India
INDUSTRY APPLICATIONS
Where UV Sterilization Chamber is Used
Related Products
Frequently Asked Questions
Low-pressure mercury UV lamps are rated for 9,000–12,000 operating hours (approximately 1–1.5 years at continuous operation). UV output degrades by 10–15% per year — replace when the UV intensity monitor reads below 70% of the initial calibrated value, or at least every 18 months regardless of intensity reading.
BIS IS 10500:2012 requires E. coli to be not detectable in 100 mL of treated water. A UV dose of ≥25 mJ/cm² reliably achieves this. Ozone India Technology UV systems are designed to deliver ≥40 mJ/cm² at end-of-lamp-life, providing a safety margin for variable water quality conditions.
No. UV disinfection is a purely physical pathogen inactivation process — it does not remove any dissolved or suspended contaminants. Water must be pre-treated to <1 NTU turbidity before UV treatment. For complete water purification including TDS, hardness, and chemical removal, combine UV with RO and/or ozone treatment.
UV systems are sized for specific UVT values. Ozone India Technology systems are standard-rated at ≥85% UVT (typical drinking water after filtration). For low-UVT water (coloured groundwater, post-secondary treated sewage at 60–70% UVT), the system is sized with additional lamp power to compensate. Provide your water's UVT% when requesting a quotation.
Yes. All UV water treatment systems carry CE marking under EU Machinery Directive 2006/42/EC and are manufactured under ISO 9001:2015 QMS. CE documentation supports export to EU, GCC, and other markets requiring CE certification for imported water treatment equipment.
